Galvanized Color Steel Roofing Iron Step Panel Automatic Roll Forming Machine Euro Tile Making Machine For Sale

  • STEELMAMA

Availability:
Quantity:


Galvanized Color Steel Roofing

 Iron Step Panel Automatic Roll Forming Machine Euro Tile Making Machine For Sale

Double Layer Roofing Machine (2)

PRODUCT DISPALY



Double layer trapezoidal roof tile building material roll forming machine

Double layer trapezoidal roof tile building material roll forming machineDouble layer trapezoidal roof tile building material roll forming machineRoof Use Corrugated IBR Glazed Profile Steel Roofing Sheet Roll Forming Machine Roof Tile Making Machinery PriceRoof Use Corrugated IBR Glazed Profile Steel Roofing Sheet Roll Forming Machine Roof Tile Making Machinery PriceCorrugated Roof Tile Metal Sheet Roll Forming Machine in Tile Making MachineryCorrugated Roof Tile Metal Sheet Roll Forming Machine in Tile Making Machinery

Corrugated Roof Tile Metal Sheet Roll Forming Machine in Tile Making Machinery


Machine Flow Chart



Main workflow of Euro Tile Making Machine

    Uncoiler  →  Molding core  →  Hydraulic System  →   Automatic Control system  →   Step Formed

 Mechanism  →  Automatic Shearing Mechanism  →   Products Receiving Tables


 Tile machine





Main Technical Parameter

color steel cold tile panel rolling machinery

Decoiler

1 set

Feeding Device  With Pre-sliding Cutter

1 set

Forming Machine

1 set

Cutting Device

1 set

PLC Control Box

1 set
  Hydraulic Pump Station 1 set
Production Support Table 1 set


 1  Decoiler

Max. Width 1000-1250mm Floor Decking Machine (7)
Inner Diameter Φ450 – Φ550 mm
Out Diameter 1500 mm
Max. Loading Capacity: 5000 kgs
Working Way Passive or hydraulic

 2  Feeding device with

    Pre-sliding cutter

tile roll forming machine

 3  Roll Forming Machine

Material Thickness 0.25-0.8mm PPGI and GI 1100 Zee Tile Cold Roll Forming Machine
NO. of Roller Stations 10-18 stations
Material for Rollers

45# steel polished and coated

with chrome HRC58-62°

Material for Shaft High grade 45# steel polished(CNC lathe)
Diameter of Shaft 70mm(Solid shaft)
Frame Panel 16*290*330mm
Bottom Frame 350x8mm H steel
Motor Power 3.8/5.5KW x 2(servo motor)
Driven Type Wall Plate Chain Drive
Chain and Gear 1", chain
Speed About 4-6m/min

 4  Cut-off Device

Material for Cut-Off Modular Cr12 steel after treatment step tile (Versatile)Roofing machine
Hardness for Heat Treatment HRC58 – 62°
Cut-Off Type Qualified pillar cutting
Motor for Hydraulic Stand 5.5KW
Punching Die Material Cr12 steel after treatment

 5  PLC Control Box

Type PLC Frequency Control System with touch screen Floor Decking Machine (5)
PLC Brand Delta  Encoder Brand: Omron
Length Error ±2mm
Language English and Chinese
Voltage 380v/50HZ, 3Phase (It depends on customer requirement)

 6  Hydraulic Pump Station

Oil type 46# hydraulic oil Floor Decking Machine (9)
Pump brand China brand
Motor power 5.5kw
Solenoid valves Huade brand
Solid valve Single
Cooling way Fan

 7  Production Support Table

Manual type

Auto stacker

Roof sheet machine 7 auto stacker


Related Plate Type

Steel roll roofing sheet machine

详情通用_03

Corrugated Type Roll Forming Sheet 详情通用_05

IBR Type Roll Forming Sheet

详情通用_07

Factory Show:

详情通用_08

1234 STEELMAMA was founded in 2009. Since its inception, STEELMAMA has always uphold the "create a first-class enterprise, first-class talents, first class contribution" vision, to create a well-known "STEELMAMA" brand.

STEELMAMA’s main business is to "project" as the theme of “CHINA STEEL AGENT SERVICE”, leading products for steel profilemachinery include roll forming machine, press brake bending machine and other steel processing machinery, and steel coil include PPGI coil, GI coil, Aluminium coil, Alu-zinc coil and steel strips and plates, also steel building material like metal roofing sheet, purlin sections, H steel, welding mill tube and some hardwares to be global brand.

123
详情通用_10

详情通用_11详情通用_12


详情通用_13详情通用_14详情通用_15

FAQ

1234

1. Does one machine can only produce one style panel profile?

Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.

2. Do you have after sales support?

Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.

3. How to visit your company?

a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour), then we can pick up you.

b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.

4. What can you do if the machine broken?

Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

5. Can you be responsible for transport?

Yes,please tell me the destination port or address.we have rich experience in transport.

6. You are trade company or factory?

We are trade company but we also have own factories. Building trade company is just for exporting various types of cold roll forming machines.

7. Why your price is higher than others?

As we persist on that each factory should put quality at the first place. We spend time and money on developing How to make machines much more automatic, accurate and high quality. We can make sure thatour machine could use more than 20 years without any problem. We can provide 2 years free qualityassurance.

8. How long the machine could be made?

Normally speaking, welded pipe making machine could be made without 45 working days. If you need machines in a hurry, we can make it for you less than a month.
