Hot Sell PLC Galvanized Metal Deck Sheet Making Machine Steel Panel Floor Deck Roll Forming Machine Price

  • STEELMAMA

Availability:
Quantity:


Hot Sell PLC Galvanized Metal Deck Sheet Making Machine

Steel Panel Floor Deck Roll Forming Machine PriceHot Sell PLC Galvanized Metal Deck Sheet Making Machine Steel Panel Floor Deck Roll Forming Machine Price


PRODUCT DISPALY

Factory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming Machine

Factory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming MachineFactory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming MachineFactory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming MachineFactory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming MachineFactory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming Machine

full automatic metal steel floor decking making roll forming machine

Machine Flow Chart



Main workflow of 960 Metal Deck Sheet Making Machine

    Uncoiler  →  Molding core  →  Hydraulic System  →   Automatic Control system  →   Step Formed

 Mechanism  →  Automatic Shearing Mechanism  →   Products Receiving Tables


Floor Decking Machine



Roll Forming Machine Components:

1

Decoiler

1 set
2

Roll Forming Machine

1 set
3

Cut-off Device

1 set
4

PLC Control Box

1 set
5 Hydraulic Pump Station 1 set

1 Decoiler

Max. Width 1000-1250mm Floor Decking Machine (7)
Inner Diameter Φ450 – Φ550 mm
Out Diameter 1500 mm
Max. Loading Capacity: 7000 kgs
Working Way Passive or hydraulic

2 Roll Forming Machine
Material Thickness 0.7-1.2mm PPGI and GI Floor Decking Machine
NO. of Roller Stations 26-32 stations
Material for Rollers

GCR15 # steel polished and coated

with chrome HRC58-62

Material for Shaft High grade 45# steel polished(CNC lathe)
Diameter of Shaft 90mm(Solid shaft)
Frame Panel
20*290*580mm
Bottom Frame 350x8mm H steel
Motor Power 11KW x 2(shanghai motor)
Driven Type Wall Plate Chain Drive
Chain and Gear
2", chain
Speed About 15m/min


3 Cut-off Device
Material for Cut-Off Modular Cr12 steel after treatment Floor Decking Machine (4)
Hardness for Heat Treatment HRC58 – 62°
Cut-Off Type

Qualified pillar cutting

Motor for Hydraulic Stand 5.5KW
Punching Die Material Cr12 steel after treatment


4 PLC Control Box
Type PLC Frequency Control System with touch screen Floor Decking Machine
PLC Brand Delta  Encoder Brand: Omron
Length Error

±2mm

Language English and Chinese
Voltage 380v/50HZ, 3Phase (It depends on customer requirement)


5 Hydraulic Pump Station


Oil type 46# hydraulic oil Floor Decking Machine (9)
Pump brand China brand
Motor power

5.5kw

Solenoid valves Huade brand
Solid valve Single
Cooling way Fan


Related Plate Type
Factory Customization Metal Galvanized Steel Sheet Floor Decking Roll Forming Machine STEELMAMA GROUP Steel roll forming machine manufacturer

Glazed Tile Type Roll Forming SheetSTEELMAMA GROUP Steel roll forming machine manufacturer

Corrugated Type Roll Forming Sheet STEELMAMA GROUP Steel roll forming machine manufacturer

IBR Type Roll Forming SheetSTEELMAMA GROUP Steel roll forming machine manufacturer


Factory Show:

详情通用_08

1234 STEELMAMA was founded in 2009. Since its inception, STEELMAMA has always uphold the "create a first-class enterprise, first-class talents, first class contribution" vision, to create a well-known "STEELMAMA" brand.

STEELMAMA’s main business is to "project" as the theme of “CHINA STEEL AGENT SERVICE”, leading products for steel profilemachinery include roll forming machine, press brake bending machine and other steel processing machinery, and steel coil include PPGI coil, GI coil, Aluminium coil, Alu-zinc coil and steel strips and plates, also steel building material like metal roofing sheet, purlin sections, H steel, welding mill tube and some hardwares to be global brand.

123
详情通用_10 详情通用_11 详情通用_12


详情通用_13详情通用_14详情通用_15

FAQ

1234

1. Does one machine can only produce one style panel profile?

Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.

2. Do you have after sales support?

Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.

3. How to visit your company?

a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi (1 hour), then we can pick up you.

b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.

4. What can you do if the machine broken?

Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

5. Can you be responsible for transport?

Yes,please tell me the destination port or address.we have rich experience in transport.

6. You are trade company or factory?

We are trade company but we also have own factories. Building trade company is just for exporting various types of cold roll forming machines.

7. Why your price is higher than others?

As we persist on that each factory should put quality at the first place. We spend time and money on developing How to make machines much more automatic, accurate and high quality. We can make sure thatour machine could use more than 20 years without any problem. We can provide 2 years free qualityassurance.

8. How long the machine could be made?

Normally speaking, welded pipe making machine could be made without 45 working days. If you need machines in a hurry, we can make it for you less than a month.

1234
